HONDA
PRO-GRESS Temp Meter
-
SENSOR ADAPTER for TYPE-G -> M32X1.5
Digital temp meter (meter body no longer in production)
Over 500cc
| Model | Year | Oil Temp Sensor | Water Temp Sensor | ||
|---|---|---|---|---|---|
| Type | Mounting Position | Type | Mounting Position | ||
| X-4 | 97-98 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CB1300SF/SB | 21 | D | Oil Pan Drain Plug | C | Radiator Hose (Adaptor Required Φ25) |
| CB1300SF/SB/ST | 03-14 | D | Oil Pan Drain Plug | X | |
| CBR1100XX | 97-98 | D | Oil Pan Drain Plug | C | Replace STD Sensor(-98) *6 |
| X-11 | D | Oil Pan Drain Plug | Replace STD Sensor *6 | ||
| CB1100F | D | Oil Pan Drain Plug | X | ||
| CB1100 | 10-14 | D | Oil Pan Drain Plug | – | |
| CB1100EX | 14 | D | Oil Pan Drain Plug | – | |
| CRF1000L AFRICA TWIN | G *5 | Oil Pan Drain Plug (Back Left) |
C | Radiator Hose (Adaptor Required) |
|
| CBR1000RR | 08-12 | G | Oil Pan Drain Plug | ||
| CBR1000RR（JAPAN） | 04 | G | Oil Pan Drain Plug | C *2 | Radiator Hose (Adaptor Required) |
| CBR1000F SUPER AERO | 93-95 | – | Not Applicable | C | Replace STD Sensor *6 |
| VTR1000F | 97-98 | G | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CB1000SF/ T2 | 93-97 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CBR929RR/ 954RR | 02 | G | Oil Pan Drain Plug | C *2 | Radiator Hose (Adaptor Required) |
| CBR900RR | 92-98 | G | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CB900F | D | Oil Pan Drain Plug | |||
| VFR800 (EFI) | 98 | – | Not Applicable | ||
| RVF750 (EFI) | 94-95 | – | Not Applicable | ||
| VFR750F | -95 | C | Replace STD Sensor *6 | ||
| VFR750R | 89 | C | Replace STD Sensor *6 | ||
| VF750/ F/ S/ M | 83- | – | Not Applicable | C | Replace STD Sensor *6 |
| CBR750 SUPER AERO | – | Not Applicable | C | Replace STD Sensor *6 | |
| CB750F II/ NIGHT HAWK | G | Oil Pan Drain Plug | |||
| CB750four K0-K7 | G | Oil Pan Drain Plug | |||
| MAGNA | 93-94 | – | Not Applicable | ||
| CB750F(FZ～FC ) | D | Oil Pan Drain Plug | |||
| NC700X | 12 | H | Oil Gallery on Lower Left Crankcase | ||
| XR650 | G | Oil Pan Drain Plug | |||
| CBR650R | 19-20 | G | Oil Pan Drain Plug | C *2 | Radiator Hose (Adaptor Required) |
| CBR600 (F4) | 00 | G | Oil Pan Drain Plug | C *2 | Radiator Hose (Adaptor Required) |
| CBR600F | C | Replace STD Sensor *6 | |||
| BROS1 (650) | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 | |
| STEED600 | -98 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| HORNET600 | 98 | C | Cylinder Head | ||
| BROS400/ 600 | 92-94 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CBX550F | G | Oil Pan Drain Plug | |||
| GB500/ 400 | G | Oil Pan Drain Plug | |||
125cc～400cc
| Model | Year | Oil Temp Sensor | Water Temp Sensor | ||
|---|---|---|---|---|---|
| Type | Mounting Position | Type | Mounting Position | ||
| GB500/ 400 | G | Oil Pan Drain Plug | |||
| CB400FOUR(CB400FE) | 76- | G | Oil Pan Drain Plug | ||
| CB400FOUR | 97- | G | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| RVF400 | 95-96 | – | Not Applicable | C | Replace STD Sensor *6 |
| VFR400R/ Z/ PRO ARM | C | Replace STD Sensor *6 | |||
| VF400F INTEGRA | C | Replace STD Sensor *6 | |||
| CBR400R/ RR | G | Oil Pan Drain Plug | C | Replace STD Sensor *6 | |
| CB400SF HYPER VTEC Revo | 08 | G | Oil Pan Drain Plug | – | Not Applicable |
| CB400SF/ verR/ S/ VTEC1,2/BOLD’OR | -03-07 | G | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CB-1 (1/2) | 89-91 | G | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CBX400F | G | Oil Pan Drain Plug | |||
| BROS400/ 600 | 92-94 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| VRX400 | -96 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| STEED400 | -98 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| NS400R | 85 | C | Replace STD Sensor *6 | ||
| CL400 | G | Oil Pan Drain Plug | |||
| GB350/S | 21 | G | Oil Pan Drain Plug | ||
| AX-1 | G | Oil Pan Drain Plug | |||
| VTR250 | 98 | G | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CBR250RR | 23 | G | Oil Pan Drain Plug | – | Not Applicable |
| 17-20 | G | Oil Pan Drain Plug | – | Not Applicable | |
| CBR250RR | -97 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CBR250R | 11-12 | G | Oil Pan Drain Plug | ||
| CBR250R | 88-89 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| CBR250F | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 | |
| JADE | 91-93 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| HORNET250 | 97-98 | D | Oil Pan Drain Plug | C | Replace STD Sensor *6 |
| NIGHT HAWK 250 | G | Oil Pan Drain Plug | |||
| CB250RS | G | Oil Pan Drain Plug | |||
| VT250F/FZ | -90 | – | Not Applicable | C | Replace STD Sensor *6 |
| XELVIS/ SPADA | -96 | – | Not Applicable | C | Replace STD Sensor *6 |
| V-TWIN MAGNA | 95-97 | – | Not Applicable | C | Replace STD Sensor *6 |
| GB250 CLUBMAN | – | Not Applicable | |||
| NSR250/ R/ 80/ 50 | 88-94 | C | Replace STD Sensor *6 | ||
| CRF250 RALLY | 23 | G | Oil Pan Drain Plug | – | Not Applicable |
| 17 | G | Oil Pan Drain Plug | – | Not Applicable | |
| CRF250L | 23 | G | Oil Pan Drain Plug | – | Not Applicable |
| 21 | G | Oil Pan Drain Plug | – | Not Applicable | |
| 12 | B (G) | Oil Pan Drain Plug | – | Not Applicable | |
| Rebel 250 | 23 | B | Blind cap on Lower Right Crankcase | – | – |
| XR250 MOTARD | G | Drain Plug Under Clutch Case | |||
| XR250/BAJA | G | Oil Pan Drain Plug | |||
| XLR250/ BAJA | G | Oil Pan Drain Plug | |||
| XLX250 | G | Oil Pan Drain Plug | |||
| XL250 | G | Oil Pan Drain Plug | |||
| XL250 DEGREE | G | Oil Pan Drain Plug | |||
| FTR223 | – | Not Applicable | – | ||
| FORESIGHT *3 | – | Not Applicable | |||
| FORZA | 21-25 | G | Oil Pan Drain Plug | – | Not Applicable |
| ADV150 | 20 | G | Oil Pan Drain Plug | – | Not Applicable |
| PCX160 | 23-25 | G | Oil Pan Drain Plug | – | Not Applicable |
| 21 | G | Oil Pan Drain Plug | – | Not Applicable | |
| PCX150 | 18 | G | Oil Pan Drain Plug | – | Not Applicable |
Up to 125cc
| Model | Year | Oil Temp Sensor | Water Temp Sensor | ||
|---|---|---|---|---|---|
| Type | Mounting Position | Type | Mounting Position | ||
| Monkey125 | 24 | G | Oil Pan Drain Plug | – | Not Applicable |
| 21-23 | |||||
| 18-20 | |||||
| CB125R | 21-24 | G | Oil Pan Drain Plug | – | Not Applicable |
| 18-20 | |||||
| CT125 | 20 | G | Oil Pan Drain Plug | – | Not Applicable |
| Super Cub C125 | 24 | G | Oil Pan Drain Plug | X | Not Applicable |
| 21-23 | |||||
| 18-20 | |||||
| Dax125 | 23 | G | Drain Plug | ||
| GROM/MSX125 | 23-24 | G | Oil Pan Drain Plug | ||
| 21 | G | Oil Pan Drain Plug | |||
| 13-16 | G | Oil Pan Drain Plug | |||
| PCX | 23-25 | G | Oil Pan Drain Plug | – | Not Applicable |
| 21 | G | Oil Pan Drain Plug | – | Not Applicable | |
| 18 | G | Oil Pan Drain Plug | – | Not Applicable | |
| 10 | G | Oil Pan Drain Plug | – | Not Applicable | |
| ZOOMER-X | 13 | G | Oil Pan Drain Plug | – | Not Applicable |
| Super Cub 110 | 22 | G | Drain Plug | ||
| 19 | – | Not Applicable | – | Not Applicable | |
| CrossCub110 | 22 | G | Drain Plug | ||
| 19 | – | Not Applicable | – | Not Applicable | |
| MBX80/ 50 | – | Not Applicable | |||
| XR100/50 Motard | G | Oil Pan Drain Plug | |||
| Ape100/50 | G | Oil Pan Drain Plug | |||
| DAX70 | 94 | G | Oil Pan Drain Plug | X | Not Applicable |
| MONKEY (12V) | G | Oil Pan Drain Plug | |||
| MONKEY | G | Oil Pan Drain Plug | |||
| MONKEY (Battery less) | – | Not Applicable | |||
| MONKEY with Yoshimura Type-1 Cyclone | – | Not Applicable | |||
| MONKEY-R | – | Not Applicable | |||
| MONKEY BAJA | – | Not Applicable | |||
| GORILLA (12V) | G | Oil Pan Drain Plug | |||
| DAX (12V) | G | Oil Pan Drain Plug | |||
| NS-1 | C | Replace STD Sensor *6 | |||
| DREAM50 | G | Oil Pan Drain Plug | |||
*1 Require Sensor Adaptor
*2 Require Water Temp Sensor Adaptor
*3 If the cord supplied with the digital thermometer is less than 2.3 m, purchase a joint cord (sold separately).
Sensor cable for PRO-GRESS 1.0m
Joint cord for digital tempmeter / L=2.3 m
*4 E Sensor (Oil Galley on Lower Right Crankcase) is recommended for installing. G Sensor (Oil Drain Plug) also possible to install.
*5 Underguard modification is required. (due to sensor code interference).
*6 Removing the STD sensor may cause the fan behind the radiator to stop functioning in some vehicles.
